EVE
EVE MB31 LiFePO4 Battery Cell 3.2V 314Ah A Grade with M6 Threaded Connectors
In stock, ready to ship
Battery type: Rechargeable
Battery technology: Lithium iron phosphate (LiFePO4)
Battery size: Other
EVE MB31 3.2V 314Ah LiFePO4 Prismatic Battery Cell
EVE MB31 lithium iron phosphate (LiFePO4) prismatic cell with M6 threaded connectors, offered for individual battery projects and professional pack assembly. Businesses requiring multiple cells can contact Voltacell for a volume quotation.
Technical specifications
- Manufacturer: EVE
- Model: MB31
- Chemistry: LiFePO4
- Nominal voltage: 3.2V
- Nominal capacity: 314Ah
- Nominal energy: approximately 1,005 Wh per cell
- Charging cut-off voltage: 3.65V
- Initial AC internal resistance: 0.18 ± 0.05 mΩ (at 1 kHz, according to the previously listed specification)
- Weight: 5,600 ± 300 g (according to the previously listed specification)
- Terminals: M6 threaded connectors
Application note: A battery management system, suitable protection and correct mechanical/electrical assembly are required when building a battery pack. Check the current manufacturer's datasheet for charging limits, temperature limits and cycle-life test conditions before system design.
Wholesale and project supply: Contact Voltacell for larger quantities and a quotation.
